SIEG SC4/210x510mm Hi-Torque Lathe
Features: Hi-Torque Brushless Motor with Torque ControlCross & Longitudinal Power FeedExtra Long 510mm BedBelt Drive for Quieter OperationCam- Lock TailstockBacklit Spindle Speed ReadoutAdvanced Touch Panel ControlT-Slots on Compound and Cross SlideCuts Metric & Imperial ThreadsMetal GearsVariable SpeedSwitched Chuck GuardLeadscrew GuardEmergency Stop ButtonHigh Quality Cast Iron BedOverload Protection Click to check how to machine a brass tap adapter on a SIEG SC4 HiTorque Lathe Specifications: Swing Over Bed 210mm Distance Between Centres 510mm Spindle Bore 20mm Spindle Taper MT3 Tailstock Taper MT2 Cross Slide Travel 100mm Compound Slide Travel 70mm Power Rating 1250W Output 1000W DC Brushless Motor Range of Threads - Metric 0.25-3.0mm (17 Thread Pitches) - Imperial 8-24TPI ( 10 Thread Pitches ) Spindle Speed 100-2000rpm Overall Dimension 1010x630x400mm Weight ( Net / Gross ) 98/125kg Standard Accessories:100mm 3-Jaw Self-Centering ChuckMT2 Dead CentreMT3 Spindle CentreChange Gear SetWrench Set Starter Kit Includes (Optional): TiN Carbide Indexable Turning Tools 7pcs Set Quick Change Tool Post with 3 Tool Holders ( Tool post with 3xRegular holders) 8mm Parting Off Tool Keyless Drill Chuck MT2 Drill Chuck Arbor HSS Drill Bit 1-6mm 51pcs Set, 0.1mm inc. Split Head from 3mm up HSS Drill Bit 6-10mm 41pcs Set, 0.1mm Inc. Split Head HSS Centre Drill Set 4pcs Set 1.6-4mm MT2 Revolving Centre 1 Year Extended Warranty Now Available! Click to learn more.
Choose a size or option at the supplier.
Observed 6 Sept 2026
View at Ausee Machines & Tools
